Tacoma Lift Kit Guide: Entry-Level to Long Travel Builds

A Tacoma lift kit can mean a set of spacers or a full long travel system, and both get sold under the same two words. The difference comes down to wheel travel, damping quality, and how much weight the truck can carry without sagging.

This guide breaks the options into five tiers. For each one you get the realistic lift height, the tire size it supports, what else you have to buy alongside it, and who it actually suits. Use it to land on the right kit the first time instead of buying twice.

We build and install these systems in our shop, so everything below reflects what holds up on customer trucks.

What a Lift Kit Changes on a Tacoma

Raising a Tacoma does four things at once:

• Improves approach, departure, and breakover angles

• Opens clearance for larger tires

• Changes front suspension geometry, since the Tacoma runs independent front suspension

• Changes ride quality, but only if the kit replaces the springs and shocks

That last point is where most builds go wrong. A spacer raises the truck without adding a single inch of travel or any damping improvement. A real Tacoma suspension upgrade swaps in coils and shocks valved for the weight you actually carry. Two trucks sitting at the same 3-inch height can ride completely differently depending on which path they took.

Tier 1: Leveling Kits and Spacers

Lift: 1 to 2 inches front
Tires: usually one size up
Ride: unchanged at best

A leveling kit removes the factory forward rake using a strut spacer or preload collar. The rear lift comes from an add-a-leaf or block. Falcon and Westcott make clean, adjustable versions of this.

Good for: a level stance and slightly bigger tires on a mostly street-driven truck.

The catch: you are compressing the same factory shock into a shorter working range. It will feel busy on the washboard.

Tier 2: Complete Bolt-On Lift Kits

Lift: 1.5 to 3 inches front, 0.5 to 1.5 inches rear
Tires: 33s with minor trimming
Ride: clearly better than stock, especially loaded

This is where most Tacoma builds should land. You get matched front coilovers and rear shocks, plus coil and leaf options chosen for your accessory weight. Bilstein 5100 and 6112/5160 packages, Dobinsons complete kits, and Old Man Emu systems all live here. Dobinsons is our pick for base-to-mid-level builds because the coil rates can be matched to a bumper and winch instead of guessed at.

Good for : Overland camping and trail rigs running armor, a rack, or a rooftop tent.

Buying tip: spec the rear first. Most owners underbuy rear spring capacity, then chase sag forever once the bumper and drawers go in. Send us your gear list and we will match the springs to it.

Tier 3: Performance Coilovers and the 3-Inch Range

Lift: adjustable, commonly 2 to 3 inches front
Tires: 33s easily, 34s or 35s with clearancing
Ride: the single biggest improvement in this whole guide

Here you move to larger shock bodies, progressive valving, and remote reservoirs. Fox 2.0 and 2.5 kits, ADS, Radflo, King, and OME BP-51 sit in this tier. A Tacoma coilover setup at this level uses a 2.5-inch front body for more consistent damping under accessory weight and rear reservoirs that add travel and shed heat on long rough sections.

Good for: forest service roads, sand, beach, and desert driven at speed.

A Tacoma 3-inch lift is the practical ceiling for a bolt-on build before geometry corrections stop being optional. If you want the best Tacoma lift for mixed use, this is the tier to stretch for. Compare our Tacoma shocks and coilovers by generation to see valving and reservoir options side by side.

Tier 4: Mid Travel

Travel: roughly 12 to 14 inches rear
Requires: shock relocation hardware, bump stops, sometimes bed or framework

Mid-travel keeps the factory width but moves the rear shocks outboard or above the frame so you can run longer shocks. Archive Garage relocation kits and packaged mid-travel systems handle this.

Good for : high-speed desert and whoop sections where a factory-length shock runs out of stroke and overheats.

Tier 5: Long Travel

Travel: 12 inches or more up front
Requires: extended control arms, custom CV axles, extended brake lines, fiberglass or cut fenders, purpose-built 2.5-inch coilovers

Long travel widens track width per side and rebuilds the front end around wheel travel. It is the largest jump in cost by a wide margin, and it makes the truck wider on tight technical trails. We install these systems in-house, including Dirt King setups.

Good for: prerunner and high-speed desert builds where travel is the entire point.

What Else Has to Change When You Lift

Lift changes caster and camber. Once you are at roughly 2.5 inches or more of front lift, you need aftermarket upper control arms to get the alignment back into spec. Skip them and you get steering wander at highway speed, uneven tire wear, and early ball joint failure.

The rest of the punch list:

• Bump stops sized to your new travel

• Sway bar relocation or extended end links

• Differential breather relocation if you see water

• U-bolts and bushings, included with most complete kits

• Alignment immediately after install

Suspension also drives the rest of the build. Tire size, bumper weight, and rack loads all feed back into the spring rate. Our 3rd gen Tacoma modifications page shows how those pieces fit together.

Pick Your Tier in One Line

• Street and fire roads, light truck: leveling kit

• Loaded overland rig: complete kit with weight-matched springs

• Mixed use with real speed off pavement: 2.5-inch coilovers with rear reservoirs

• Desert and whoops: mid-travel

• Prerunning: long travel

Buy for the truck you drive, not the one in the build thread.

FAQ

How much lift do I need for 33-inch tires?
Most Tacomas are clear 33s with a 2- to 3-inch front lift and minor trimming. Fitment shifts with wheel offset and generation.

Do I need upper control arms with a 3-inch lift?
Yes. At 2.5 inches or more of front lift, factory arms cannot be aligned back into spec.

Will a lift kit hurt my ride quality?
A spacer can. A matched coilover and spring package almost always improves it, especially with weight on board.

How long does installation take?
A complete bolt-on kit with control arms is typically a full day plus alignment. Mid and long travel are multi-day jobs.

Still Not Sure Which Tier Is Yours?

Send us three things, and we will spec it for you:

1. Your Tacoma's year and generation

2. What is bolted to it now, or what do you plan to add (bumper, winch, rack, tent, drawers)

3. Where you actually drive it, and how fast

We will come back with a matched kit, the control arms and hardware it needs, and the real total. No guessing on spring rates, no parts you do not need.
